ADVANCED HYBRID CONTRIBUTION VIDEO ENCODER
The DMNG RACK180 is an advanced hybrid contribution video encoder designed for installation in newsgathering vehicles to expand their capabilities by adding transmissions over bonded cellular networks.
DMNG RACK180 HIGHLIGHTS
The DMNG RACK180 incorporates in a compact 1U rack-mount chassis the same hardware and software core as the industry-leading DMNG PRO180 and embeds 8 x 3G/4G modems, 1 x Wi-Fi modem and 2 x best-in-class H.264 video encoders.
Thanks to AVIWEST's SafeStreams® technology and its intelligent bonding stack, the DMNG RACK180 expands the newsgathering vehicle's capabilities by taking advantage of both satellite and cellular networks in various scenarios:
Broadcast live video or recorded files over bonded cellular networks while driving.
Ensure transmission resiliency by using bonded cellular connections as a seamless back-up to satellite when weather conditions or congested networks make the satellite bandwidth fluctuate.
Increase the overall transmission capacity by bonding all together satellite and cellular network connections.
The DMNG RACK180 has 8 SMA antenna connectors on its rear panel to plug 2 AVIWEST QUAD wideband external cellular antenna arrays that can be easily installed on the roof of vehicle.
The QUAD antennas are designed to strenghen the signal transmission in critical environment such as live from crowed areas or transmission on the move.
DMNG RACK180 MAIN SPECIFICATIONS
|
|
Main Functions
|
Live & Auto-record
Store & Forward
Progressive Store & Forward
|
|
Other Functions
|
IFB Return Channel
Tally Light
Geolocation
|
|
Video Inputs
|
HD/SD-SDI embedded audio (BNC)
Composite (BNC)
Analog Audio L&R (BNC)
HDMI (1.3)
|
|
Network Interfaces
|
8 x 3G/4G built-in modems
8 x SMA antennas connectors for QUAD
2 x additional external USB modems
Built-in Wi-Fi
BGAN, Thuraya
KA band Satellite
Ethernet
|
|
Other Interfaces
|
ASI-TS out (BNC)
2 x Gigabit Ethernet (streaming, BGAN,...)
2 x USB 2.0 (Store, USB modems,...)
Stereo mini jack (3.5mm) in & out (IFB)
mini jack (3.5mm) for Tally Light
RS232, RS485
SD Card slot (Store)
|
|
Networking
Protocols
|
RTP Unicast streaming
RTP Multicast streaming (IGMP)
MPEG-2 Transport Stream over UDP/IP
RTMP, RTSP, HLS
|
| |
|
Video Encoding
|
H.264/AVC Main/High Profile level 4
1080i/720p/576i/480i
@ 50/59.94/25/29.97 fps
Bit rates: 100Kbps to 15Mbps
CBR / VBR / Capped VBR
Simultaneous Live & Store at different bitrates
|
|
Audio Encoding
|
AAC-LC/HE-AACv2; 24 to 256Kbps
MPEG-1 Layer II; 32 to 384Kbps
Dual Mono / Stereo
|
|
Advanced Features
|
Simultaneous Live & Store at different bitrates
(Dual encoding)
HD & SD downscaling
Forward Error Correction (FEC)
AES Encryption 128-bit or 256-bit (Optional)
|
|
Operational Modes
|
Glass to glass latency: 1 sec min
Preset profiles & manual modes
|
|
Configuration
& Monitoring
|
Touch Screen
On screen video preview
Remote configuration: Web GUI (any devices)
Remote control from receiver (DMNG Studio)
Remote control from manager (DMNG Manager)
|
|
Power Supply
|
Dual 12-24V input XLR 4 pins
Max. power consumption: 42W
Average power consumption: 30W
|
|
Physical
|
Format: 1RU, width 19"
Depth: 112 mm / 4.4 in
Weight (Kg): 2 Kg / 4.4 Lb
Operating temperatures: -10°C to 50°C
|
|
ORDERING INFORMATION
|
|
Code
|
Products Description
|
|
AW-DR180
|
DMNG RACK180 1RU unit
|
|
|
|
|
Code
|
Related Product
|
|
AW-QUAD
|
QUAD wideband cellular antenna array
delivered with:
3-meter RG174 cables
4 anti-slip magnetic pads
|
|
|
|
Code
|
Software Options
|
|
AW-OT-AES
|
AES encryption (128-bit or 256-bit)
|
|
AW-OT-PTZ
|
PTZ licence
|
|
|
|
|
Code
|
Options Description
|
|
AW-OT-TAL
|
Tally Light
|
|
AW-OT-BR1
|
Male RCA-BNC 0.5m cable
|
|
AW-OT-BR2
|
Male RCA-BNC 1.5m cable
|
|
AW-OT-BR3
|
Female RCA-BNC 0.5m cable
|
|
AW-OT-SDI
|
Angled SDI adapter
|
|
