THE ULTIMATE 3G/4G-LTE UPLINK SYSTEM
The AVIWEST DMNG PRO series is the world’s most advanced pocket sized 3G/4G-LTE video uplink system product line designed for news gathering professionals. DMNG PRO systems are deployed worldwide and used by number of international, national and local TV channels and news agencies on a daily basis.
DMNG PRO180-RA HIGHLIGHTS
With up to 10 cellular connections (8 x 3G/4G-LTE internal modems with internal high efficiency custom antenna array and 2 USB interfaces for additional USB modems) plus a Wifi connection (built-in Wifi modem) and integrating the best-in-class H.264 video encoder, the unit is able to stream a high definition live video down to the receiver with a delay that’s short enough to allow seamless interviews.
The DMNG PRO180-RA has 8 MCX antenna connectors on its front panel into which 2 AVIWEST QUAD wideband external cellular antenna arrays can be plugged to strenghen the signal transmission in critical environment such as live from crowed areas (street demonstrations, sport stadiums,..) or from vehicles on the move.
Weighing about 1Kg, the portable DMNG PRO180 can be easily connected to any professional camera (SD/HD SDI, analog (BNC) and HDMI in) and mounted on with its V-Mount, Gold Mount or PAG lok plates.
Designed for video professionnals, the unit is automaticaly set-up according to the real time networks capabilities. The friendly and intuitive touch screen interface allows any media professionnals on the move to easily configure and operate the system using the Live and the Store & Forward functions, talk to its studio with the IFB return channel. The units can also be controled by the receiver (DMNG Studio) or any device connected to the unit though the network.
DMNG PRO180-RA MAIN SPECIFICATIONS
|
|
Main Functions
|
Live & Auto-record
Store & Forward
Progressive Store & Forward
|
|
Other Functions
|
IFB Return Channel
Tally Light
Geolocation
|
|
Video Inputs
|
HD/SD-SDI embedded audio (BNC)
Composite video (BNC)
Analog Audio L&R (BNC)
HDMI (1.3)
|
|
Network Interfaces
|
8 x 3G/4G built-in modems
8 x 3G/4G High gain Custom Antennas (Option)
8 MCX antenna connectors for QUAD
Built-in Wi-Fi modem with patented high-efficiency antenna
2 x USB 2.0 ports
Dual Gigabit Ethernet (LAN, WAN, BGAN, Thuraya, KA band Satellite)
|
|
Other Interfaces
|
ASI-TS out (BNC)
2 x USB 2.0 ports (Forward, external USB modems, etc.)
SD Card slot (Store)
Stereo mini jack (3.5 mm) in & out (for Intercom)
Mini jack (3.5 mm) for Tally Light
Expansion port (RS232, RS485)
|
|
Networking
Protocols
|
RTP Unicast streaming
RTP Multicast streaming (IGMP)
MPEG-2 Transport Stream over UDP/IP
RTMP, RTSP, HLS (DMNG Studio)
|
| |
|
Video Compression
|
H.264/AVC Main/High Profile level 4
1080i/720p/576i/480i
@ 50/59.94/25/29.97 fps
Bit rates: 100Kbps to 15Mbps
CBR / VBR / Capped VBR
Simultaneous Live & Store at different bitrates
|
|
Audio Encoding
|
AAC-LC/HE-AACv2; 24 to 256Kbps
MPEG-1 Layer II; 32 to 384Kbps
Dual Mono / Stereo
|
|
Advanced Features
|
Dual encoding (Live & Auto-record)
(Dual encoding)
HD & SD downscaling
Forward Error Correction (FEC)
AES Encryption (128-bit or 256-bit) (Optional)
|
|
Operational Modes
|
Glass-to-glass latency: down to 1s
Preset profiles & manual modes
|
|
Monitoring & Configuration
|
Rotating Touchscreen
On screen video preview
Remote Configuration: Web GUI (any devices)
Remote control from receiver (DMNG Studio)
|
|
Power Supply
|
12-24V input XLR 4 pins - Hot swap
Average power consumption: 30W
Max. power consumption: 45W
Female V-Mount, Gold Mount or PAGLOK plate
Male V-Mount, Gold Mount or PAGLOK plate
|
|
Physical
|
Dimensions: 245x128x55 mm
Weight (Kg): 1.16
Weight (Lb): 2.55
Operating temperatures: -10°C to 50°C
|
|
ORDERING INFORMATION
|
|
Code
|
Products Description
|
|
AW-DP180A-V
|
DMNG PRO180-RA with V-Mount plates
delivered with:
1 x DC adapter
1 x Transportation case
|
|
AW-DP180A-G
|
DMNG PRO180-RA with Gold Mount plates
delivered with:
1 x DC adapter
1 x Transportation case
|
|
AW-DP180A-P
|
DMNG PRO180-RA with PAG lok plates
delivered with:
1 x DC adapter
1 x Transportation case
|
|
|
|
Code
|
Hardware Options
|
|
AW-OT-INA
|
8 x internal 3G/4G high gain custom antennas
|
|
|
|
|
Code
|
Software Options
|
|
AW-OT-AES
|
AES encryption (128-bit or 256-bit)
|
|
AW-OT-PTZ
|
PTZ licence
|
|
|
|
|
Code
|
Options Description
|
|
AW-OT-TAL
|
Tally Light
|
|
AW-OT-BPV
|
DMNG PRO Backpack V-Mount version
|
|
AW-OT-BPG
|
DMNG PRO Backpack Gold Mount version
|
|
AW-OT-ICA
|
DMNG PRO car cigarette lighter power adapter
|
|
AW-OT-BR1
|
Male RCA-BNC 0.5m cable
|
|
AW-OT-BR2
|
Male RCA-BNC 1.5m cable
|
|
AW-OT-BR3
|
Female RCA-BNC 0.5m cable
|
|
AW-OT-SDI
|
Angled SDI adapter
|
|
AW-OT-EUC
|
Expansion-USB cable for Panasonic HPX600
|
|
AW-OT-VMB
|
100W V-Mount battery
|
|
AW-OT-GMB
|
100W Gold Mount battery
|
|
AW-OT-TC3
|
Spare Transportation case
|
|
AW-OT-PA3
|
Spare DC adapter
|
|
